ABB AX521

ABB AX521

Product information：

Brand：ABB                             Model number：AX521

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: Sweden

Price: Please contact us                   Product weight：0.13kg

HS: 8517623990

Product technial information：

ABB AX521 Product Detailed Description

The ABB AX521 is an analog input/output module belonging to the S500 I/O series within ABB's AC500 PLC (Programmable Logic Controller) automation platform. This module provides a combination of analog input and output channels, making it versatile for various industrial automation applications. Specifically, the AX521 features 4 analog input channels that can be configured for voltage (U), current (I), or Resistance Temperature Detector (RTD) signals, and 4 analog output channels configurable for voltage (U) or current (I) signals. It also supports 1-wire configuration. The module offers a 13-bit resolution (including sign) for accurate analog signal processing.

Product Parameters

Here are some key technical parameters of the ABB AX521 module:

• Product ID: 1SAP250100R0001

• ABB Type Designation: AX521

• Analog Inputs: 4 (configurable for U, I, RTD)

• Input Signal Types: Voltage (0 V ... 10 V, -10 V ... +10 V), Current (0 mA ... 20 mA, 4 mA ... 20 mA), RTD (Pt100/1000, Ni1000)

• Resolution: 12 bits (for voltage and current), typically ±0.5% of full scale accuracy at 25°C

• Analog Outputs: 4 (configurable for U, I)

• Output Signal Types: Voltage (-10 V ... +10 V), Current (0 mA ... 20 mA, 4 mA ... 20 mA)

• Resolution: 12 bits (+ sign), typically ±0.5% of full scale accuracy at 25°C

• Process Voltage: 24 V DC (rated value, max. 5% ripple)

• Current Consumption: Approx. 2 mA from the CPU/communication interface module's 24 V DC supply, 0.15 A + output loads from UP

• Galvanic Isolation: Yes, per module

• Wiring: 2/3-wire for sensors

• Dimensions (Net): Width 67.5 mm, Height 76 mm, Depth/Length 62 mm

• Weight (Net): 0.129 kg

• Degree of Protection: IP20 (Housing)

• Operating Temperature: 0 °C to +60 °C (horizontal mounting, derating for vertical)

• Storage Temperature: -40 °C to +70 °C

• Mounting: DIN rail

Product Advantages

The ABB AX521 offers several advantages in industrial automation systems:

• Versatile Analog I/O: Combines both analog input and output functionalities in a single module, saving space and cost.

• Configurable Channels: Each input and output channel can be independently configured for different signal types (voltage, current, RTD), providing flexibility for various sensor and actuator types.

• High Resolution and Accuracy: 12-bit resolution ensures precise analog signal acquisition and control.

• Wide Range of Input Types: Supports common analog signals and temperature sensors (RTDs).

• Robust Design: Suitable for industrial environments with an operating temperature range of 0 °C to +60 °C and IP20 protection.

• Galvanic Isolation: Provides electrical isolation between the module and the system, enhancing reliability and preventing ground loops.

• Integration with AC500 Platform: Seamlessly integrates with ABB's AC500 series PLCs and other S500 I/O modules.

• Compact Size: Space-saving design allows for efficient installation in control cabinets.
